业内领先的八大功能:
★ 防潮防尘设计:全国独家防潮、防尘设计,主机箱自动恒温技术
★ 最高灵敏度在门的正中间可以检测到一根大头针(或者1/2)回型针。
★ 可以在排除皮带扣、皮鞋、文胸的影响。
★ 门板采用经过特种工艺处理制成的烤漆PVC,边上是铝合金支柱,防雨、防火、防撞,不会划伤。
★ 2侧门柱灯:门体2侧均带有高亮度LED报警显示灯。
★ 先进的高亮度数码LED显示通过人数和报警人数以及功能调试等,方便操作。
★ 多场合使用模式灵敏度可以根据需要调整,共有一百级灵敏度。
★ 门头主机面板设有防区报警显示和门体2侧均带有高亮度LED报警显示灯双重显示功能。
一、功能介绍:
◆ 防潮防尘设计:全国独家防潮、防尘设计,主机箱自动恒温技术。
◆ 探测精度:最高灵敏度在门的正中间可以检测到一根大头针(或者1/2)回型针,可以做到走一百次检测到一百次,不会漏报和串报。也可以在排除皮带扣、皮鞋、文胸的影响,检测到150克以上的铜、铝、锌等金属或者管制刀具和枪支。
◆ 六防区显示:产品分成六个防区,可疑物体能在每个区域准确显示。
◆ 统计人数:可以检测到通过人数和报警人数,走100人计100人,不会多计或者少计.
◆ 防震设计:站在门的中间,用手拍两侧门板,不误报。
◆ 灵敏度可调:灵敏度可以根据需要调整,共有两百级灵敏度。
◆ 门体材质:门板采用经过特种工艺处理制成的烤漆PVC,边上是铝合金支柱,防雨、防火、防撞,不会划伤。
◆ 二侧门柱灯:门体二侧均带有高亮度LED报警显示灯,能直观地通过二侧门柱灯显示违禁物品所在的区域,视角可达180°,声光同时报警,报警时间长短可调。
◆ 面板显示:先进的高亮度数码LED显示通过人数和报警人数以及功能调试等,方便操作。
◆ 多场合使用模式设计:灵敏度可以根据需要调整,共有一百级灵敏度,安装和操作更加简单。
◆ 便捷的操作模式:可以通过面板上的操作键对参数进行调试。参数可设密码保护,使非授权人员无法操作。
◆ 开发预留功能:预留通讯接口,可以与电脑、摄像头、三轧辊等连接。
◆ 抗干扰能力:针对各种使用环境的电磁干扰,整个系统采用了世界先进的电磁兼容设计,并使用DSP处理器对违禁物品的采样信号进行相关运算和滤波,从而使得整套设备具有极强的电磁抗干扰能力。
◆ 频段选择:可设定多组工作频率,使得多台设备并排相邻工作时,互不干扰。
◆ 无任何辐射伤害:对心脏起博器佩带者、孕妇、磁性介质等无害。
二:技术标准:
1、电器参照EN60950安全标准执行。
2、辐射参照EN50081-1标准执行。
3、抗干扰参照EN50082-1标准执行。
4、严格执行(GB15210-2003)版,现行通过式金属探测器国家标准。
5、全面通过ISO9001:2000质量管理体系认证。
6、全面通过欧盟CE认证。
三、技术参数:
1、外接电源:110V - 250V 50/60Hz
2、功耗:35W
3、工作环境:-20℃─+55℃
4、运输全重:约90kg
5、工作频率:根据安装环境自行调节
6、整机重量:约90kg
7、外形尺寸:(mm)2220(高) x 820(宽) x610(深)
8、通道尺寸:(mm)2000(高) x 700(宽) x 610(深)
四、超值服务:
1、1个月包换、5年保修、终身维护。
2、即日起,凡在我公司购买所有产品,凭收据、发票对老客户实行依旧换新及产品升级服务。
Leading eight functions in the industry:
Water-proof and dust-proof design: exclusive water-proof and dust-proof design of the country, automatic constant temperature technology of the main chassis
The highest sensitivity can detect a pin(or 1/2) clip in the middle of the door.
You can rule out the effects of belt buckles, leather shoes, and bras.
The door plate adopts a painted PVC made of special processing. The edge is an aluminum alloy pillar. It is rainproof, fireproof, and collision proof and will not scratch.
<UNK> 2 side door column light: both sides of the door body have high-brightness LED alarm display lights.
The advanced high-brightness digital LED display is easy to operate through the number of people and the number of alarms and functional debugging.
In many cases, the mode sensitivity can be adjusted as needed, with a total of 100 levels of sensitivity.
The main panel of the door head is equipped with an area alarm display and both sides of the door body are equipped with a double display function of high-brightness LED alarm display lights.
Introduction to functions:
Design of moisture and dust prevention: exclusive moisture and dust control design of the country, the main engine box automatic constant temperature technology.
